| Image Sensor |
1/3” 4Megapixel progressive CMOS (0.8467 centimeter) |
| Minimum Illumination |
Colour: 0.003Lux (F1.6, AGC ON) 0Lux with IR on |
| BodyType |
Bullet |
| Shutter Speed |
Auto/Manual, 1~ 1/100000s |
| White Balance |
Auto/Outdoor/Fine Tune/Sodium Lamp/Locked/Auto2 |
| Lens |
2.8~12mm Motorized |
| Gain Control (AGC) |
Auto/Manual |
| Angle of View |
102.79°~ 30.86° (H), 54.50°~17.49° (V), 106.94°~35.49° (O) |
| Video Compression |
Ultra 265, H.265, H.264, MJPEG |
| Wavelength |
850nm |
| Lens Type |
Motorized |
| S/N Ratio |
>56dB |
| Max. Aperture |
F1.6 |
| Back Light Comp. |
BLC / HLC / WDR(120dB) |
| Video Streaming |
Main Stream: 4MP (2688×1520), Max 30fps; 4MP (2560×1440), Max 30fps; 3MP (2304×1296), Max 30fps; 1080P (1920×1080), Max 30fps Sub Stream: 720P (1280×720), Max 30fps; D1 (720×576), Max 30fps; (640×360),Max 30fps; 2CIF(704×288), Max 30fps; CIF(352×288), Max 30fps |
| DORI Distance |
2.8mm- 63.0m (Detect) 25.2m (Observe) 12.6m (Recognize) 6.3m (Identify) 12mm- 270.0m (Detect) 108.0 (Observe) 54.0 (Recognize) 27.0m (Identify) |
| Flip |
Normal/Vertical/Horizontal/180°/90°Clockwise/90°Anti-clockwise |
| Motion Detection |
Up to 4 areas |
| Privacy Mask |
Up to 4 areas |
| ICR |
IR-cut filter with auto switch (ICR) |
| ROI |
Up to 8 areas |
| Audio Compression |
G.711 |
| Audio Input |
Built-in Mic |
| Bit Rate |
128 Kbps~16 Mbps |
| Protocol |
IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, SSL, QoS, 802.1x, SNMP; ONVIF (Profile S, Profile G, Profile T), API |
| Ethernet |
1 x RJ45 10M/100M Base-TX Ethernet |
| Smart Phone |
iPhone, iPad, Android Phone |
| IR Range |
Array Range of 50 Mtr., Smart IR |
| Micro SD |
Micro SD, up to 256GB |
| Operating Temperature |
-30°C~ 60°C (-22°F ~ 140°F), Humidity: ≤95% RH (non-condensing) |
| Power Source |
DC 12V±25%, PoE (IEEE 802.3af) |
| Power Consumption |
Max 8.5W |
| Weatherproof Standard |
IP67 |
| Dimension |
206 × 74 × 74mm (8.1” × 2.9” × 2.9”) (L × W × H) |
| Casing |
Metal |
| Weight |
0.55 kg |
