| Image Sensor |
1/2.8” 2MP PS CMOS Image Sensor (7.112 centimeters) |
| Minimum Illumination |
Colour: 0.0005 Lux (F1.2, AGC ON) B/W:0.0001 Lux(F1.2, AGC ON) |
| BodyType |
Box |
| Shutter Speed |
Auto/Manual, 1~1/100000 s |
| White Balance |
Auto/Manual |
| Lens |
C/CS Mount Lens |
| AGC Control |
Auto/Manual |
| Video Compression |
Ultra 265, H.264, MJPEG |
| S/N Ratio |
>52dB |
| Back Light Comp. |
BLC/ HLC/WDR(120dB) |
| Frame Rate |
Main Stream:2MP (1920×1080): Max. 30 fps; Sub Stream: 2MP (1920×1080): Max. 30 fps; Third Stream:D1 (720×576): Max. 30 fps |
| Video Streaming |
Triple |
| Video Output |
1 BNC, impedance 75 O; amplitude 1 V [p-p] |
| Resolution |
1920 × 1080 |
| Motion Detection |
Up to 4 areas |
| Privacy Mask |
Up to 8 areas |
| ICR |
IR-cut filter with auto switch (ICR) |
| ROI |
Up to 8 areas |
| Interface |
1 RS485 (support Pelco-D/P) |
| Audio Input |
impedance 35 kO; amplitude 2 V [p-p] |
| OSD |
Up to 8 OSDs |
| Audio Output |
impedance 600 O; amplitude 2 V [p-p] |
| Audio Compression |
G.711 |
| Audio |
Two-way audio Supported |
| Alarm IN |
2 Ch. IN |
| Alarm Out |
1 Ch. Out |
| Protocol |
IPv4, IGMP,ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP,DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, 802.1x, QoS , ONVIF (Profile S & G), API |
| Ethernet |
10M/100M Base-TX Ethernet |
| Micro SD |
Micro SD, up to 256 GB |
| Operating Temperature |
-20°C ~ +60°C (-4°F ~ 140°F) |
| Humidity |
10%~90% RH (non-condensing) |
| Power Source |
24 V AC±10%, 12 V DC±10%, PoE (IEEE802.3 af) |
| Power Consumption |
Max 6.8W |
| Dimension |
151.5 x 71 x 65 mm (6.0“ x 2.8“ x 2.6”) |
| Weight |
0.48 kg |
