| Image Sensor |
1/1.8” 4Megapixel progressive CMOS (1.411 cm) |
| Minimum Illumination |
0.001 Lux@F1.6 (Color, 30IRE) 0.0002 Lux@F1.6 (B/W, 30IRE) 0 Lux (IR On) |
| Effective Pixels |
2688 (H) × 1520 (V) |
| Shutter Speed |
Auto/Manual, 1/3~1/100000s |
| White Balance |
Auto/natural/street lamp/outdoor/manual/regional custom |
| S/N Ratio |
>56dB |
| Lens |
8~32mm Motorized Lens |
| Iris |
Auto; Precise iris control |
| Gain Control (AGC) |
Auto/Manual |
| Video Compression |
H.265, Smart H.264+, H.264, H.264H, H.264B, MJPEG (only supported by sub stream) |
| Encode Strategy |
Instastream |
| Close Focus Distance |
W: 2.5m ; T: 6m |
| Angle of View |
Horizontal: 40° (W)–15° (T) Vertical: 23° (W)–9° (T) Diagonal: 46° (W)–18° (T) |
| Max Aperture |
F1.6 (Constant) |
| Back Light Compensation |
BLC/ HLC/ WDR(140dB) |
| Lens Type |
Motorized |
| Video Streaming |
Main Stream: 2688 × 1520 (1–50/60 fps) Sub stream: 704 × 576 (1–25fps);704 × 480 (1–30fps) Third stream: 1920 × 1080 (1–25/30 fps) Fourth stream: 1920 × 1080 (1–25/30 fps) Fifth stream: 704 × 576 (1–25fps); 704 × 480 (1–30fps) |
| DORI Distance |
W: 151m (Detect) 60.7m (Observe) 30.3m (Recognize) 15.1m (Identify) T: 400m (Detect) 160m (Observe) 80m (Recognize) 40m (Detect) |
| Mount Type |
Module interface |
| Privacy Mask |
4 areas |
| ICR |
Auto (ICR)/Color/B/W |
| Resolution |
4MP (2688 × 1520), 3MP (2304 × 1296), 1080P (1920 × 1080), 1.3MP (1280 × 960), 720P (1280 × 720), D1 (704 × 576/704 × 480), VGA (640 × 480), CIF (352 × 288/352 × 240) |
| ROI |
Yes (4 areas) |
| Motion Detection |
OFF/ON (4 areas, rectangular) |
| Audio Input |
1 Ch. |
| Audio Output |
1 Ch. |
| Audio Compression |
G.711a; G.711Mu; G726; G.723 |
| Alarm IN |
3 channel In: 5mA 5V DC |
| Alarm Out |
2 channel Out: 1000mA 30V DC/500mA 50V AC |
| Bit Rate |
H.264: 32 kbps-10240 kbps ; H.265: 12 kbps-10240 kbps |
| Cloud Health Monitoring System (HMS) |
Support |
| OTA (Online Device Upgrade) |
Support |
| Smart Detection |
Abandoned object, moving object |
| Protocol |
IPv4; IPv6; HTTP; HTTPS; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; 802.1x; SNMP; Bonjour ; ONVIF (Profile S/Profile G/Profile T); CGI; Milestone; Genetec; InstaOn; RTMP |
| Video Metadata |
Support human body, human face, motor vehicle and non-motor vehicle image capture and attributes extraction |
| Face Recognition |
Face detection; track; snapshot; snapshot optimization; optimal face snapshot upload; face enhancement; face exposure; face attributes extraction including 6 attributes (gender, age, glasses, expressions, mask, and beard) and 8 expressions (angry, sad, disgusted, scared, surprised, calm, happy, confused); face snapshot set as face or one-inch photo; snapshot strategies (recognition priority and optimization snapshot); face angle filter; optimization time setting. Support 5 face databases; register one by one or in batches; support face recognition similarity settings and face comparison on the basis of 100,000 face databases. |
| Ethernet |
RJ-45 (10/100/1000 Base-T) |
| People Counting |
Support tripwire number counting, people counting in area, and displaying and outputting yearly/monthly/daily reports. Support queue management, and displaying and outputting monthly/daily reports. Support 4 tripwire rules configuration, people counting in 4 areas, and 4 queue management functions. |
| Smart Phone |
iPhone, iPad, Android Phone |
| SDK and API |
Yes |
| Perimeter Protection |
Tripwire, intrusion, fast moving (the three functions support the classification and accurate detection of vehicle and human); parking detection, loitering detection, and people gathering |
| Intelligent Search |
Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos. |
| Cyber Security |
Video encryption; firmware encryption; configuration encryption; Digest; WSSE; account lockout; security logs; IP/MAC filtering; generation and importing of X.509 certification; syslog; HTTPS; 802.1x; trusted boot; trusted execution; trusted upgrade |
| IR |
IR Range of 120 Mtr., Smart IR |
| Alarm Event |
No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering; tripwire; intrusion; fast moving; abandoned object; missing object; loitering detection; people gathering; parking detection; scene changing; audio detection; defocus detection; external alarm; face detection; people counting in area; stay alarm; people counting; people counting exception detection; safety exception, Queue Management |
| Micro SD |
FTP; Micro SD card (512GB); NAS; SFTP |
| Operating Temperature |
-40°C to +60°C (-40°F to +140°F), /Less than 95% RH |
| Storage Temperature |
-40°C to +65°C (-40°F to +149°F) |
| Power Source |
12V DC/24V AC/PoE+ (802.3at), ePoE, max. current 165mA |
| Power Consumption |
12.2W (12V DC);17.3W(24V AC); 17.1W (PoE) Heat power consumption: 3.3W (12V DC); 5.5W(24V AC); 5.5W (PoE) |
| Weatherproof Standard |
IP67 & IK10 |
| Casing |
Metal + Plastic |
| Dimension |
340.1 mm × 108.5 mm × 92.9 mm (L × W × H) |
| Weight |
1600g |
